PROVEN LONG-TERM DURABILITY
For residential pool & spa
The SB Series pump delivers high flow and energy efficiency ultra performance. 2-inch suction and discharge port with a transparent lid. Ring lock seal design to eliminate suction leaks and to maximize suction efficiency.

1. 2 inch suction and discharge port with transparent lid
2. Asynchronous, Two poles motor
3. Class insulation: 130(B)
4. IPX5 Waterproof standard
5. Built-in thermal protection
6. Overload protection
7. Available in 50Hz or 60Hz with 220V/380V
8. Special design union compatible with both Imperial and Metric measurement standard
9. S.S. 316 Shaft
10. S.S. 316 Mechanical seal
11. Self-Priming up to 2m above water level
12. Testing Pressure 50PSI (3.5 Bar)
13. Ring lock Lid design to eliminate suction leaks and maximize suction efficiency

PROVEN LONG-TERM DURABILITY
For residential pool & spa
The SB Series pump is the right choice for both high and medium head installation in commercial spa pools. The seal and bearing used are imported from trustable suppliers to ensure reliable quality. It delivers high flow and energy efficiency ultra performance.

1. 2 inch suction and discharge port with transparent lid
2. Asynchronous, Two poles motor
3. Class insulation: 130(B)
4. IPX5 Waterproof standard
5. Built-in thermal protection
6. Overload protection
7. Available in 50Hz or 60Hz with 220V/380V
8. Special design union compatible with both Imperial and Metric measurement standard
9. S.S. 316 Shaft
10. S.S. 316 Mechanical seal
11. Self-Priming up to 2m above water level
12. Testing Pressure 50PSI (3.5 Bar)

THE BEST OPTION FOR SMALLER PLUMBING
For the small size residential pools or above-ground poolsThe SS pump is quiet running and energy efficient.1.5-inch suction and discharge port with a transparent lid. It operates at a low decibel and energy consumption which requires minimal maintenance.
Additional features for timer option: • No need to install an external timer for the pump.
• Set up the ideal switch-on time and the run-time ranging from 2 hours a day to 24 hours.
• Battery backup memory for up to 72 hours.

1. 1.5 inch suction and discharge port with transparent lid
2. Asynchronous, Two poles motor
3. Class insulation: 130(B)
4. IPX5 Waterproof standard
5. Built-in thermal protection
6. Overload protection
7. External heat sink
8. Available in 50Hz or 60Hz with 220V/110V
9. Special design union compatible with both Imperial and Metric measurement standard
10. S.S. 316 Shaft
11. S.S. 316 Mechanical seal

QUIET OPERATION AND EASY INSTALLATION
For the above-ground pools or portable spas
ST Series Pump has the option to have the pre-filter disassembled which allows users a greater degree of applications. 1.5-inch suction and discharge port with a transparent lid. It operates at a low decibel and energy consumption which requires minimal maintenance.

1. 1.5 inch suction and discharge port with transparent lid
2. Asynchronous, Two poles motor
3. Class insulation: 130(B)
4. IPX5 Waterproof standard
5. Built-in thermal protection
6. External heat sink
7. Available in 50Hz or 60Hz with 220V/110V
8. Special design union compatible for both Imperial and Metric measurement standard
9. S.S.316 Shaft
10. S.S.316 Mechanical seal

FOR HEAVY DUTY SERVICE POOLS
For fresh water commercial poolsSE Series Commercial Iron Pump build to cater commercial usage (e.g Large-size swimming pool, spa pool, water feature, etc). Cast iron body with easy to clean large strainer basket. Stainless Steel or Metal Impellers options are available to match your need, range from 5.5HP to 15HP, suitable for heavy-duty commercial usage (e.g. Large size swimming pool, commercial spa pools, water features). Renowned ABB motor is used to ensure quiet and stable operation.

1. Cast iron body with AISI-304 S.S. basket
2. AISI-304 S.S. or Cast iron Impellers are optional to match your need.
3. Available with ABB motor
4. Asynchronous, Two poles motor
5. Class insulation: 130(B)
6. IP55 Waterproof standard
7. Built-in thermal protection
8. Overload protection
9. Available in 380V/50Hz
10. Testing Pressure 50PSI (3.5 Bar)
11. Basket Volume 5 litres

PROVIDE LARGE FLOW AND HIGH EFFICIENCY
For countercurrent system, water circulation, and commercial spaAFS Series pump is designed for the countercurrent system and SPA system. High-performance design provides large flow and high efficiency.

1. Class insulation: 155(F)
2. IPX5 Waterproof standard
3. Low noise level
4. Build-in thermal protection
5. Stator applied by molding process with moisture resistance and heat security
6. Complete separation of water and the shaft, safe and reliable
7. High-quality wear-resistant mechanical seal

CREATE BUBBLE STREAM TO YOUR POOL
For both commercial and portable spaWith low energy consumption, AB Series Economy Air Blower offers high-efficiency operation in a compact design that fits for limited space installation.

• Air blower is applicable in bath tub or spa tub, with 220V, 350W motors.

CREATE BUBBLE STREAM TO YOUR POOL
For both commercial and portable spa

HB Series Commercial Air Blower performs high-pressure air delivery and vacuum function. It is suitable for the spa usage with Picks spa jets and fittings. Compact blowers for air or gas, pressure or vacuum with motors from 1 to 2 Hp (0.75 to 1.5 kW).

1. Continuous duty rating with quality motors
2. Blowers are CE certified and can be customized for any application
3. High-temperature designs for up to 50oC
4. Assorted coatings and platings for corrosive environments
5. Available for 50Hz and 60Hz

Features:
Optimized working point in design with features of large flow and high efficiency.
Pump wet end made of high strength engineering plastic.
With wear-resisting mechanical seal system
Impeller for three phase motor fixed by key and nuts, no worry about the reverse direction rotation of motor
Motor stator processed by plastic packaging technology, moisture-proof, thermal conductivity, safety.
The motor shaft isolated from liquid, safety and reliable.

Motor:
Asynchronous, two poles, IP 55 protection, Class F insulation, Continuous operation. Single phase motor with thermal protection.

Picks WTB300T, Picks WTB400T

Swimming Pool Pump SWIM S1

Performance Range:
Max. Head: 28m
Max. Flow: 18.5m3/h
Max. Suction: 2.5m
Power: 0.5hp to 2.0hp

Operating Limits:
Max. liquid temperature: 50℃
Ambient temperature: 50 ℃
Max. working pressure: 3 bar
Liquid: thin, clean, non-condensation, non-flammable, non-explosive, without solid particles or fibers liquid.

The Silen S2 range are a highly efficiency range of swimming pool pumps designed using the latest technology by the industry approved experts at ESPA Pumps and offer unbeatable performance whilst minimising power consumption.

Designed for commercial applications, the Silen series of swimming pool pumps are perfect when it comes to the filtering and recirculation of water treated with chlorine in larger sized pools.

The Silen swimming pool pump includes a handy in-built pre-filter strainer box which collects leaves, debris and insects and makes the job of clearing these very simple.

Available in both single phase and three phase.

Bearings rated for chlorinated water up to 160 degrees C such as swimming pools, spas and bathing pools.

The pump body is engineered from extremely tough technopolymer and you can be assured of quality due to the stainless steel shaft. Abrasion resistance is enhanced further by the inclusion of specially designed impeller which is suited to withstand sands and silts etc.

The ESPA Silen range of swimming pool pumps also benefit from being ultra-silent and noise friendly.

Rated for continuous use.

HIGH PERFORMANCE & HEAVY DUTY
For residential and semi-commercial poolsRing lock seal design eliminate suction leaks and maximize suction efficiency

FEATURES

1. Asynchronous, Two poles motor
2. Class insulation: 130(B)
3. IPX5 Waterproof standard
4. Built-in thermal protection
5. Overload protection
6. Available in 50Hz or 60Hz with 220V/380V
7. Special design union compatible with both Imperial and Metric measurement standard
8. S.S. 316 Shaft
9. S.S. 316 Mechanical seal
10. Self-Priming up to 2.5m above water level
11. Testing Pressure 50PSI (3.5 Bar)
12. Basket Volume 5 litres

Picks EPH-300, Picks EPH-400
